Why Nero water?
Nero water is passed through 12 stage multiple
filters. Manufactured in hygienic, sterilize, sanitary atmosphere.
"NERO" water is OZONISED & good for health. It
is Iron, Chlorine, Bacteria, Virus free.
Drinking nero water increases working capacity
& also solves the stomach problem.
It is pure & safe drinking water for
your good health.
FLOW CHART OF WATER TREATMENT PLANT
Raw water drawn from deep bore well will passes
through submersible pump/pump stored in a under ground storage
tank then it pumped through a high presser pump where in sodium
hypo chloride will mix with water through automatic dosing pump
to OXIDISATION chamber which removes the excess iron in the
water after passing through oxidization chamber water having
iron is less then .001ppm then water passes through DUEL MEDIA
Filter which have 100 micron the suspended particles in the
water will remove from that filter then water passes through
ACTIVETED CARBON FILTER of 50 micron ACF will absorbed the smell
in the water then water passes through R.O Block where TDS of
water comes down to 10/15 water then blended in permeate tank
for required specification then blended water passes through
ACF 2 to remove smell and then water passes through different
micron filters having capacity of 5 to 0.1 micron where virus/bacteria
will remove water then passes through U.V & finally through
ozonisation for better quality and self life.
 |
